CCS2 to GB/T DC Fast Charging Adapter
A high-current charging adapter designed to connect compatible CCS2 DC fast charging stations to electric vehicles equipped with a GB/T charging inlet.
Built for Cross-Standard DC Charging
Designed for selected commercial, fleet, engineering and international EV charging applications.
CCS2 Charger to GB/T Vehicle
Connects a compatible CCS2 DC charging cable to an electric vehicle equipped with a GB/T charging inlet.
Up to 300A DC
Supports high-current DC charging applications with a maximum rated current of up to 300A.
Up to 1000V DC
Suitable for high-voltage charging systems with a maximum rated voltage of up to 1000V DC.
Temperature Monitoring
Integrated temperature monitoring helps identify abnormal heat conditions during charging.
Automatic Shutdown
The adapter is designed to stop charging when abnormal temperature conditions are detected.
IP55 Protection
Durable PC and ABS housing provides protection against dust and water jets under specified conditions.
Technical Specifications
Verify the vehicle and charging station parameters before ordering.
| Product Type | CCS2 to GB/T DC Fast Charging Adapter |
|---|---|
| Charging Direction | CCS2 Charging Station to GB/T Vehicle |
| Charger-Side Interface | CCS2 DC Charging Socket |
| Vehicle-Side Interface | GB/T DC Charging Connector |
| Maximum Current | Up to 300A DC |
| Rated Voltage | Up to 1000V DC |
| Protection Rating | IP55 |
| Operating Temperature | -30°C to +50°C |
| Housing Material | Flame-Retardant PC + ABS |
| Flammability Rating | UL94 V-0 |
| Safety Protection | Temperature Monitoring and Automatic Shutdown |
| Product Weight | Approximately 2.1 kg |
| Product Dimensions | 312 × 114 × 197 mm |
| Warranty | 12 Months |
Interfaces and Product Structure
Review the charger-side interface, vehicle-side connector, dimensions and practical charging configuration.
CCS2 Charging Cable Input
Charger-side input for a compatible CCS2 DC charging cable.
GB/T Vehicle Connector
Vehicle-side connector for a compatible GB/T DC charging inlet.
Product Dimensions
Overall product dimensions: 312 × 114 × 197 mm.
Charging Application
CCS2 charging station connected to a compatible GB/T electric vehicle.
What Is a CCS2 to GB/T Charging Adapter?
A CCS2 to GB/T DC charging adapter enables an electric vehicle equipped with a GB/T charging inlet to connect to a compatible CCS2 DC fast charging station.
The CCS2 charging cable connects to the input side of the adapter. The GB/T connector on the output side is inserted into the vehicle charging inlet.
Typical users include vehicle importers, fleet operators, EV service providers, charging equipment companies, laboratories and international EV projects.
How the Adapter Works
Confirm the vehicle, charging station and adapter configuration before beginning the charging process.
Connect the CCS2 Cable
Insert the CCS2 charging cable into the CCS2 input socket of the adapter.
Connect the GB/T Vehicle
Insert the GB/T connector into the vehicle’s GB/T DC charging inlet.
Confirm the Connection
Verify that the vehicle, charger and adapter have established a valid connection before charging.
Designed for High-Power DC Charging
High-current charging requires stable electrical contact, temperature management and durable housing construction.
Temperature Monitoring
Monitors temperature conditions at critical charging points during operation.
Automatic Shutdown
Stops the charging process when abnormal temperature conditions are detected.
Flame-Retardant Housing
PC and ABS housing with a UL94 V-0 flammability rating.
IP55 Protection
Designed to resist dust and water jets under specified test conditions.
Vehicle and Charger Compatibility
Compatibility must be confirmed according to the vehicle model, production year, charging inlet, charging station output, communication configuration and software version.
- Vehicle brand and model
- Vehicle production year
- Vehicle charging standard
- Charging station brand and model
- Maximum charging voltage
- Maximum charging current
- Destination country
Typical Application Scenarios
Imported GB/T Vehicles
Charging Chinese-standard electric vehicles in markets where CCS2 DC infrastructure is available.
Commercial Fleets
Supporting selected fleet operators using GB/T vehicles across CCS2 charging environments.
Vehicle Testing
Used by EV manufacturers, laboratories and engineering teams for charging validation.
EV Conversion Projects
Suitable for selected charging interface integration and vehicle conversion projects.
Charging Service Providers
Helps service providers support vehicles using different regional charging standards.
Cross-Border EV Projects
Supports international projects involving vehicles and chargers from different markets.
Frequently Asked Questions
Is this adapter designed for a CCS2 vehicle?
No. It is designed for a GB/T vehicle that needs to connect to a compatible CCS2 DC charging station.
What is the charging direction?
The charging direction is from a CCS2 DC charging station to a GB/T electric vehicle.
What is the maximum rated current?
The stated maximum rated current is up to 300A DC. Actual charging current depends on the vehicle, charger, battery and operating conditions.
Does it work with every CCS2 charging station?
Universal compatibility should not be assumed. Compatibility depends on the charging station, vehicle, communication system, electrical parameters and software configuration.
Does the adapter support protocol conversion?
Communication functions depend on the selected product configuration. Please provide the vehicle and charging station model before quotation.
Is the adapter waterproof?
The enclosure has an IP55 protection rating. It is designed to resist dust and water jets under specified conditions, but it must not be immersed.
Can you provide OEM services?
OEM branding, packaging and selected customization options can be discussed for qualified bulk orders.
Confirm Compatibility Before Ordering
Send us your vehicle model, model year, charging inlet, charging station model, required quantity and destination country.
Request Compatibility Check
